181
Option Esc External Source Control
Using Option ESC with the Keysight MXG Signal Sources.
Manually entering conversion loss data
NOTE It is possible to add a description and a comment of what the selected correction is,
and have this description appear on the Description or Comment key. Press
Properties, and connect a keyboard to the instrument. For example, press Comment
and type 11970V Serial XXxxxxxxxx. Press Done.
Action Notes
1 Locate the printed copy of the
conversion loss data that has the
text "For use with Keysight
X-Series analyzers only".
Or
Insert the CD provided with the
mixer into a PC and navigate to
the 70xxxxxx_X.pdf file.
The file contains tabular and graphic
conversion loss data. Be careful to select
the correct file since there are three files
provided for the 11970A, Q and V band
mixers. Print the 70xxxxxx_X.pdf file to
create a printed copy.
2 Press Input/Output, More,
Corrections, Select Correction.
3 Choose a correction array from
the list of Correction 1 through
Correction 6.
Correction 1 has a provision to store
antenna corrections, so if antenna
corrections are required, reserve this array
for that use.
4 To see if anything is already
stored in a particular correction,
press Correction, Edit.
Selecting Edit turns the correction ON. Be
sure to turn the correction OFF after
determining the contents of the correction
array.
5 To delete a correction table, press
Return, assure the Select
Correction key corresponds to the
correction you want to delete, and
press Delete Correction.
6 Select the correction number and
press Edit.
When finished press Return.
Use the keys provided to enter the
frequency and amplitude (conversion loss)
points from the calibration data table.
Conversion loss values are entered as
positive numbers.
