Chapter 1: Product Overview
14
DVR User’s Manual
16-Channel DVR
VGA
AUDIO IN (CH5-CH16)
HDMI
LAN
1
2
AUDIO OUTVIDEO OUT AUDIO IN
2
4
1
3
MAIN
SPOT
CH8
CH16
CH7
CH15
CH6
CH14
CH5
CH13
CH4
CH12
CH3
CH11
CH2
CH10
CH1
CH9
G 12345678910 11
+
- NO COM G1615141312
RS-485
D+ D -
KB OUT IN
ALARM
12V
1 2 3 54 76 8 9 12 131110
No. Connector Descripon
1 Video input Connects to a maximum of 16 video input devices via BNC.
2 Video output Connects to a video output device via BNC.
3
Video SPOT
output
Connects to a video output device via BNC wherein only channels with VIDEO OUTPUT
seng congured to SPOT-OUT are displayed.
4 Audio input Connects to a maximum of 4 audio input devices via BNC.
5 Audio output Connects to a maximum of 2 audio output devices via BNC.
6 HDMI output Connects to a monitor output via HDMI.
7 Parallel input Connects to a maximum of 12 audio input using a Parallel-to-BNC adapter.
8 VGA output Connects to a VGA monitor.
9 LAN Connects to LAN via RJ-45.
10 USB port Connects to a USB mouse, ash disk, and other external storage drive.
11 RS-485 Connects to a Speed dome camera, sensor or alarm device via RS-485.
12 Power switch Press to turn the DVR on or o.
13 Power Connects to the power adapter.
1.4 Mouse
The DVR is supplied with a USB mouse that you can use to operate the DVR. Simply plug in the supplied mouse into
the USB mouse connector at the rear panel of the device.
Mouse Operaon Descripon
Le-click In OSD menu, click the le buon to select and edit the seng.
Right-click In preview mode, click the right buon to display the pop-up menu.
In main menu or sub menu mode, click the right buon to exit the current menu.
Double-click the Le buon Double-click the live image of any channel for full screen display. Double-click the le
buon again to return to the window-display of all cameras.
Drag an area/line In moon mode, use this funcon to select moon area.
In [Color Setup] menu mode, it will adjust color control bar.
