ENGLISH
Chapter 4: Using the DVR
40
DVR User’s Manual
Menu item Descripon
Video Output Select one of the following:
• LIVE-OUT: To set the video output seng of the main monitor used for live
view display.
• SPOT-OUT: To set the video output seng of the monitor connected to the
SPOT-out connector of the DVR.
View Setup Select Enable to enable view setup.
Note:
When View Setup is enabled, Split Windows funcon is not available (see “3.4.2
Split Mode” on page 33).
View Mode Select how you want to split the windows, opons are: Single, Quarter, Ninth,
Sixteenth.
VOUT Sequence /
SPOT Sequence
Click VOUT Sequence or SPOT Sequence to set the order of how the channels
appear.
Rotate Time Set the interval me (in seconds) when changing screen display in Rotate mode.
See “3.4.4 Rotate View” on page 34.
VGA/HDMI
Resoluon
Select the output resoluon.
Init. DEV
(Inial Device)
Select where you want to display the OSD menu when mulple monitors are
connected to the DVR (Video Out, VGA, or Auto).
Transparency Hide or display the recording me while recording.
Volume Click Volume to adjust the output volume or mute the audio.
4 Aer all sengs are complete, click Apply.
5 When data saving is complete, click OK.
