Instrument panel (Driver’s side fuse panel)
Fuse Name Symbol Fuse rat‐
ing
Circuit Protected
MODULE 5 10A
Crash Pad Switch, ECM (Electro Chromic Mirror), Audio / Video &Navigation Head Unit,
Head Lamp Le
veling Device Actuator LH/RH, Front Seat Warmer Control Module, Rear
Seat Warmer Control Module, Auto Head Lamp Leveling Device Module, Front Air Ven‐
tilation Seat Control Module, Amp
MODULE 4
10A
Crash Pad Switch, MFC Module, AEB Module, Blind Spot Detection, Radar Left Handle
side/Right Handle side, VESS, C
onsole Upper EXTN (STR'G WHEEL HEATED)
INTERIOR
LAMP
10A
Luggage Lamp, Front Vanity Lamp LH/RH, Room Lamp, Overhead Console Lamp, Rain
Sensor
, Wireless Charger
A/BAG
15A ACU (Airbag Control Unit), ODS
E-SHIFTER 1 10A Console Upper EXTN (SBW)
IG 1 25A PCB Block (FUSE- IEB2, EPCU2)
CLUSTER 10A Cluster
MODULE 3 10A BCM (Body Control Module), Driver/Passenger Door Module, Stop Lamp Switch
IG3 2 10A
Fuel Filler Door & Battery Charge Switch, Cluster, Charger Indicator, Air Conditioner
C
ontrol Module, Audio/Video & Navigation Head Unit, Audio, IG3, PTC Heater, Charge
Control Module
MEMORY 2
7.5A VESS, BATT_COOL_EXV
A/BAG IND 7.5A Cluster, Air Conditioner Control Module
START 7.5A EPCU, Smart Key Control Module
Maintenance
8-44
