Maintenance Fuses
A/BAG2 10A SRS (Supplemental Restraint System) Control Module
CLUSTER 7.5A Instrument Cluster, Head-Up Display
MODULE4 10A
E-Call Unit, Audio, Audio/Video & Navigation Head Unit, Data
Link Connector, Front Air Conditioner Control Panel, Head
Lamp Left Handle side/Right Handle side, Front Air Condi
-
tioner Control Module, Crash Pad Switch, Electro Chromic
Mirror, IMS (Integrated memory system) Control Module, 1st
Air Ventilation Seat Control Module, 1st Seat Warmer Control
Module, 2nd Seat Warmer Left Handle side/Right Handle side
Control Module
MODULE7 7.5A IBU (Integrated Body Control Unit)
MULTI MEDAI2 10A RSE Left Handle side/Right Handle side
BRAKE SWITCH 7.5A IBU (Integrated Body Control Unit), Stop Lamp Switch
MDPS 7.5A
MDPS (Motor Driven Power Steering) Unit
* MDPS (Motor Driven Power Steering) is same as EPS (Elec
-
tric Power Steering).
Fuse Name Symbol Fuse rating Circuit Protected
2
CLUSTER
MODULE
4
MODULE
7
MULTI
MEDIA
2
BRAKE
SWITCH
MDPS
