Kia Sorento 2021 - Page 698

Maintenance
787
Fuses
MODULE6 7.5A Fuel Filter Heater & Pressure/Temperature Sensor
USB CHARGER1 10A
Luggage USB Charge Connector Left Handle side/Right Han -
dle side
USB CHARGER2 15A
Rear Console USB Charge Connector Left Handle side/Right
Handle side, Driver/Passenger Seat USB Charge Connector
MODULE3 7.5A
IBU (Integrated Body Control Unit), ADAS Unit, Front Camera
(ADAS), Crash Pad Switch, Surround View Monitor Unit, Rear
Radar Left Handle side/Right Handle side, 4WD (4 Wheel
Drive) ECU (Electronic Control Unit), DCU (Dosing Control
Unit), Front Console Switch, Driver/Passenger Seat Ventila
-
tion Switch, Front Radar, ATM (Automatic Transmission)
Shift Lever (Indicator)
A/BAG1 15A SRS (Supplemental Restraint System) Control Module
WASHER 15A Multifunction Switch
MODULE1 10A
AMP (Amplifier), RSE Left Handle side/Right Handle side, Low
DC-DC Converter, Audio, IBU (Integrated Body Control Unit),
Audio/Video & Navigation Head Unit, ADAS Unit, E-Call Unit,
Front USB Charge Connector Left Handle side/Right Handle
side, Surround View Monitor Unit
MODULE9 10A
Key Solenoid, Driver/Passenger Mood Lamp, ADAS Unit, Data
Link Connector
IBU1 7.5A IBU (Integrated Body Control Unit)
MODULE2 7.5A Overhead Console, DAU, Multifunction Switch
RR A/CON1 15A
Rear Air Conditioner Blower Motor, ICU Junction Block (Fuse -
MEMORY)
A/BAG IND 7.5A Instrument Cluster, Overhead Console
MODULE8 7.5A
ADAS Unit, 1st Air Ventilation Seat Control Module, 1st Seat
Warmer Control Module, Rear Air Conditioner Control Module,
2nd Seat Warmer Left Handle side/Right Handle side Control
Module
IBU2 15A IBU (Integrated Body Control Unit)
MODULE10 10A
Stop Lamp Switch, ATM (Automatic Transmission) Shift
Lever
MODULE5 10A
Overhead Console, AMP (Amplifier), Front Wireless Charger
Unit, Low DC-DC Converter
A/CON 7.5A
Front Air Conditioner Control Module, Front Air Conditioner
Control Panel, Engine Room Junction Block (PTC Heater #2
Relay, Blower Relay)
Fuse Name Symbol Fuse rating Circuit Protected
MODULE
6
USB
CHARGER
1
USB
CHARGER
2
MODULE
3
1
MODULE
1
MODULE
9
IBU
1
MODULE
2
REAR
A/C
1
IND
MODULE
8
IBU
2
MODULE
10
MODULE
5
A/C
