Maintenance Fuses
PCB Block
Fuse Name Symbol Fuse r Ating Circuit Protected
IG2 40 A
Engine Room Junction Block (Start Relay), PCB (Printed Circuit
Board) Junction Block (IG2 Relay)
IG1 40 A PCB (Printed Circuit Board) Junction Block (IG1 Relay, ACC Relay)
FRT WIPER2 7.5 A IBU (Integrated Body Control Unit)
SENSOR6 20 A
[Smartstream D2.2] Front/Rear Nox Sensor, PM Sensor
[Smartstream G3.5] Oxygen Sensor #2/#4
SENSOR1 20 A
[Smartstream D2.2] Rail Pressure Control Valve
[Smartstream G2.5] Ignition Coil #1/#2/#3/#4
[Smartstream G3.5] Ignition Coil #1/#2/#3/#4/#5/#6
SENSOR8 10 A GCU
ECU2 10 A ECM (Engine Control Module)/PCM (Power train Control Module)
SENSOR5 10 A
[Smartstream D2.2] Engine Room Junction Block (Fuel Pump Relay,
Fuel Filter Heating Relay)
[Smartstream G2.5] Engine Room Junction Block (Fuel Pump Relay)
[Smartstream G3.5] Engine Room Junction Block (Fuel Pump Relay)
SENSOR9 20 A
[Smartstream D2.2] Fuel Metering Valve
[Smartstream G3.5] ECM (Engine Control Module)
SENSOR3 20 A ECM (Engine Control Module)/PCM (Power train Control Module)
SENSOR2 15 A
[Smartstream D2.2] Lambda Sensor #1/#2
[Smartstream G2.5] Oxygen Sensor (Up/Down)
[Smartstream G3.5] Oxygen Sensor #1/#3
FRT WIPER1 30 A Front Wiper Motor
RR WIPER 15 A Rear Wiper Relay, Rear Wiper Motor
HORN 15 A Horn Relay
A/CON2 10 A A/Con Relay
B/ALARM
HORN
15 A Burglar Alarm Horn Relay
E-SHIFTER3 7.5 A SCU
TCU2 10 A TCM (Transmission Control Module)
