Maintenance
827
Fuses
FUSE
TRAILER1 50 A Trailer Module
ABS3 60 A ESP (Electronic Stability Program) Control Module
B+3 50 A ICU Junction Block (Instrument Panel Module)
TRAILER2 20 A Trailer Module
FUEL PUMP 20 A Engine Room Junction Block (Fuel Pump Relay)
CHILD LOCK 15 A
PCB (Printed Circuit Board) Junction Block (Child Lock/
Unlock Relay)
BLOWER 50 A Engine Room Junction Block (Blower Relay)
B+4 50 A
ICU Junction Block (Fuse - AMP, LDC, S/HEATER FRT, P/
WINDOW RH, S/FOLD RL)
B+1 40 A
ICU Junction Block (Long Term Load Latch Relay, Fuse -
T/GATE, DR LOCK, S/HEATER RR, START, MODULE9,
IBU2, A/BAG2, BRAKE SWITCH)
4WD 20 A 4WD (4 Wheel Drive) ECU (Engine Control Unit)
TCU1 15 A PCM (Power train Control Module)
AMS 10 A Battery Sensor
E-SHIFTER2 10 A SCU, Electronic Shift Dial
DCU3 10 A DCU (Dosing Control Unit)
HTD MIRR 10 A
Front Air Conditioner Control Panel, Front Air Conditioner
Control Module, Driver Power Outside Mirror
A/CON1 10 A Front Air Conditioner Control Module
DCU2 20 A DCU (Dosing Control Unit)
DCU4 20 A DCU (Dosing Control Unit)
Fuse Name Symbol Fuse r Ating Circuit Protected
1
3
3
2
FUEL
PUMP
4
1
T1
AMS
E-
SHIFTER
2
DCU
3
A/C
1
DCU
2
DCU
4
