Kikusui PCR 2000M - Connecting the Power Cord

PCR-M 25
Chapter 2 Installation and Preparation
2.6 Connecting the Power Cord
The power cord provided with the product varies depending on the type. This
product is designed as an equipment of IEC Overvoltage Category II (energy-
consuming equipment supplied from the fixed installation).
Possible electric shock.
• This product is an IEC Safety Class I equipment (equipment with a
protective conductor terminal). Be sure to ground (earth) the unit.
• Connect the protective conductor terminal to earth ground.
• PCR500M
Connect the power cord to a properly grounded power outlet.
• PCR1000M / PCR2000M
Make sure to connect the (GND) terminal of the AC INPUT terminal block
to the GND terminal of the switchboard.
PCR500M
The AC power cord that is provided varies depending on the destination for the
product at the factory-shipment.
• Use the supplied power cord to connect to the AC line.
If the supplied power cord cannot be used due to the rated voltage or the plug
shape, have a qualified engineer replace it with an appropriate power cord of
length 3 m or less. If obtaining a power cord is difficult, consult your Kikusui
agent or distributor.
• The power cord with a plug can be used to disconnect the PCR-M from the AC
line in an emergency. Connect the plug to an easily accessible power outlet so
that the plug can be removed from the outlet at any time. Be sure to allow
enough space around the power outlet.
• Do not use the supplied power cord on other instruments.
page 72
1. Check that the AC power line complies with the input rating of the PCR-M.
The voltage that can be applied is any of the nominal power supply voltages in the
range of 100 Vac to 120 Vac or 200 Vac to 240 Vac. The frequency is 50 Hz or 60 Hz.
• If the voltage distortion of the AC power line is large, it can lead to
malfunction. The PCR-M cannot be connected to a generator or a similar
device.
2. Check that the POWER switch is turned off.
3. Connect the power cord to the AC INPUT inlet on the rear panel.
4. Insert the power plug to an outlet.
WARNING
See
CAUTION
