Kikusui PCR 2000M - Rear Panel

14 PCR-M
Rear panel
No. Name Description
Page
1
OUTPUT terminal block Output terminal block with a cover
30
2
Air outlet Exhaust port for cooling
–
3
RS232C A connector for RS232C remote control
75
4
Option slot Installs an option board.
17
5
AC INPUT PCR500M: AC inlet
PCR1000M / PCR2000M: AC input terminal block
25
6
AUX A connector for functional expansion
–
7
Serial number Serial number of PCR-M series
–
1
15
2
2
34
34
56
6
7
7
152
34
6
7
PCR500M
PCR1000M
PCR2000M
See
