Kikusui PCR 2000M - Analog Interface Specifications (EX04-PCR-M Option)

76 PCR-M
Chapter 6 Specifications
Analog interface specifications (EX04-PCR-M option)
Total performance when the EX04-PCR-M is installed in the PCR-M.
Items not listed below conform to the specifications of the PCR-M.
PCR-M series
Input
terminal
Maximum allowable input voltage ±15 V
Type BNC
Input impedance 10 k
Ω ± 5 % (unbalanced)
Isolation voltage ±100 Vmax
EXT-AC
mode
*1
Input voltage range 0 V to ±10 V (DC)
Voltage amplification ratio (135 V/
270 V range)
13.5x/27x
(Outputs an AC voltage of 0 V to 135 V/0 V to 270 V with respect to
a DC voltage input of 0 V to 10 V)
Frequency setting range 40 Hz to 500 Hz
Other output rating specifications Same as the specifications of the output rating for AC mode
EXT-DC
mode
Input voltage
range
When ATT is
OFF
0 V to ±1.90 Vpeak (0 V to 1.35 Vrms sine wave)
When ATT is ON 0 V to ±10 V (DC)
Input
frequency
range
When ATT is
OFF
*2
40 Hz to 500 Hz (Sine wave) /40 Hz to 100 Hz (Rectangular wave)
/DC
Frequency
characteristics
When ATT is
OFF
-0.3 dB at 500 Hz with respect to 55 Hz (typical value)
Voltage
amplification
ratio
(135 V/270 V
range)
When ATT is
OFF
100x/200x
(Outputs an AC voltage of 0 V to 135 V/0 V to 270 V with respect to
a AC voltage input of 0 V to 1.35 V)
When ATT is ON
19x/38x
(Outputs a DC voltage of 0 V to ±190 V/0 V to ±380 V with respect
to a DC voltage input of 0 V to ±10 V)
Other output rating specifications Same as the specifications of the output rating for DC mode
Output voltage distortion ratio
*3
PCR-M specifications + 0.5 % or less
Output voltage temperature coefficient PCR-M specifications + 200 ppm/°C (typical value)
Insulation
resistance
Between input (BNC) and chassi,
input (BNC) and output
500 Vdc, 30 M
Ω or more
Withstand
voltage
Between input (BNC) and chassi,
input (BNC) and output
500 Vac for 1 minute
*1. ATT ON at all times
*2. The measurable range of voltage, current, and power is DC and 40 Hz to 500 Hz.
Set the frequency according to the input waveform period.
*3. When DC voltage is applied for EXT-AC mode or when a sine wave with distortion ratio of 0.1 % or less is
applied for EXT-DC mode.
