Kikusui PCR 2000M - Chapter 6 Specifications 6.1 Specifications; Electrical Specifications

72 PCR-M
Chapter 6 Specifications
6.1 Specifications
Unless specified otherwise, the specifications are for the following settings and
conditions.
• The warm-up time is 30 minutes (with current flowing).
• Typical value: Typical values do not guarantee the performance.
• set: Indicates the setting.
•rdng: Indicates the reading.
Electrical specifications
PCR500M PCR1000M PCR2000M
Input rating
AC input
Nominal input rating 100 V to 120 V/200 V to 240 V, 50 Hz/60 Hz, single phase
Input voltage range
90 V to 132 V/180 V to 250 V (auto detected when the power is
turned on)
Input frequency range 47 Hz to 63 Hz
Apparent power 800 VA or less 1 600 VA or less 3 200 VA or less
Power factor
*1
0.9 (typical value)
Current
(Input AC voltage 90 V to 132 V/180 V to 250 V)
9 A/4.5 A or less 18 A/9 A or less 36 A/18 A or less
Output rating for AC mode
Voltage range
(135 V/270 V
range)
Rated voltage range 1 V to 135 V/2 V to 270 V
Preset voltage range 0 V to 137.5 V/0 to 275 V
Voltage setting resolution 0.1 V
Voltage setting accuracy
*2
±(1 % of set + 0.6 V/1.2 V)
Output phase Single phase
Maximum current
*3
5 A/2.5 A 10 A/5 A 20 A/10 A
Maximum peak current
*4
15 A/7.5 A 30 A/15 A 60 A/30 A
Load power factor 0 to 1 (leading phase or lagging phase)
Power capacity 500 VA 1 000 VA 2 000 VA
Frequency setting range 40 Hz to 500 Hz
Frequency setting resolution 0.1 Hz
Frequency accuracy
Within ±2×10
-4
Output rating for DC mode
Voltage range
(135 V/270 V
range)
Rated voltage range 1.4 V to 190 V/2.8 V to 380 V
Preset voltage range -194 V to 194 V/-388 V to 388 V
Voltage setting resolution 0.1 V
Voltage setting accuracy
*5
±(1 % of set + 0.6 V/1.2 V)
Maximum current
*6
4 A/2 A 8 A/4 A 16 A/8 A
Maximum instantaneous current
*7
12 A/6 A 24 A/12 A 48 A/24 A
Power capacity 400 W 800 W 1 600 W
