PCR-M 75
Chapter 6 Specifications
RS232C interface specifications
GPIB interface specifications (IB21 option)
USB interface specifications (US21 option)
Common interface specifications
PCR-M Series
Hardware
Complies with EIA-232-D
D-SUB 9-pin connector (male) *1
*1. Use a cross cable (null modem cable).
Baud rate: 1 200, 2 400, 4 800, 9 600, or 19 200 bps
Data length: 8 bits, stop bit: 1 bit, and parity bit: None
Flow control: Xon/Xoff
Program message terminator LF during reception, CR/LF during transmission
PCR-M Series
Hardware
Complies with IEEE Std 488.1-1978
SH1, AH1, T6, L4, SR1, RL1, PP0, DC1, DT1, C0, E1
Program message terminator LF or EOI during reception, LF+EOI during transmission
Primary address 1 to 30
PCR-M Series
Hardware Complies with USB 2.0. Data rate: 12 Mbps (full speed).
Program message terminator LF or EOM during reception, LF+EOM during transmission
Device class Complies with the USBTMC-USB488 device class specifications
PCR-M Series
Software protocol IEEE Std 488.2-1992
Command language SCPI Specification 1999.0
Operation
details
Functions expanded
during remote control
*1
*1. There are no specifications for the accuracy.
Apparent power measurement
Reactive power measurement
Power factor measurement
Crest factor
Peak hold current measurement
Functions expanded when
an option is installed
*2
*2. Activated when the GPIB, USB, or analog interface is installed and during remote control.
AC + DC mode
(The specifications of output rating such as the voltage range,
maximum current, and power capacity are the same as those of the
DC mode.)
Panel storage memory: 10 memories *3
*3. Includes the three standard memories.
