PCR-M 85
Appendix
A.4 Glossary
Rated output (power) capacity or power capacity
The maximum value (unit: VA) of the output power capacity that can be
continuously supplied when the output voltage is 100 V to 135 V (for the 135 V
range) or 200 V to 270 V (for the 270 V range) and the output frequency is 40 Hz to
500 Hz in AC mode or when the output voltage is 100 V to 190 V (for the 135 V
range) or 200 V to 380 V (for the 270 V range) in DC mode.
Table A-3 Power capacity
The power capacity in DC mode is 80 % of that of AC mode.
Rated maximum current
The maximum value (unit: A) of the output current (rms value) that can be
continuously supplied when the output voltage is 100 V (for the 135 V range) or 200
V (for the 270 V range) and the output frequency is 40 Hz to 500 Hz in AC mode or
when the output voltage is 100 V (for the 135 V range) or 200 V (for the 270 V
range) in DC mode.
The maximum current in DC mode is 80 % of that of AC mode.
Rated output current
■ For AC mode
The maximum continuous value of the output current (rms value) that has been
reduced by the output voltage.
■ For DC mode
The maximum continuous value of the output current (unit: A) that has been
reduced by the output voltage.
Maximum peak current (AC mode only)
page 80
The maximum continuous value (unit: Apeak) of the output current (peak value)
that the PCR-M can supply to a capacitor input-type rectifying load when the output
voltage is 100 V to 135 V (for the 135 V range) or 200 V to 270 V (for the 270 V
range) and the output frequency is 40 Hz to 500 Hz.
Maximum peak current = Rated maximum current (rms value) × 3
PCR500M PCR1000M PCR2000M
Power capacity 500 VA 1 000 VA 2 000 VA
=
Rated output (power) capacity [VA, W]
Output voltage 100 V or 200 V
Rated maximum current
See
