BioMax2 / KBio2-Online
Installation and Programming Manual
www.kimaldi.com Page 14 of 91
4.5. Connection details, KBio2-Online
J1 - Main Connector:
Pin 1 - Positive Power Supply Pole (+5 VDC).
Pin 2 - Negative power supply pole (GND) (Pin no. 5 SubD female connector).
Pin 3 - UART_0 - Tx 232 Signal to Host (Pin no. 2, SubD female connector).
Pin 4 - UART_0 - Rx 232 Signal to Host (Pin no. 3, SubD female connector).
Pin 5 - Digital Input 0.
Pin 6 - Pole A of Relay 0.
Pin 7 - Pole B of Relay 0.
J2: Keypad connector:
Pin 1 - Red LED Anode (+). Pin 5 - Keypad supply (+5 VDC).
Pin 2 - Green LED Anode (+). Pin 6 - IN Key.
Pin 3 - Yellow LED Anode (+). Pin 7 - F1 Key.
Pin 4 - Common Cathode (GND). Pin 8 - F2 Key.
J3 - TTL_0 Connector to card Reader (NdCAN compatible):
Pin 1 - Data signal (TTL_0)
Pin 2 - Clock signal (TTL_0)
Pin 3 - CLS signal (TTL_0)
Pin 4 - Output +5 VDC
Pin 5 - Negative power supply pole (GND)
J4: Connection to FIM biometric identification module or to generic RS-232 reader
Pin 1 - +5 VDC Output
Pin 2 - UART_1 - Tx 232 signal to reader or FIM Module
Pin 3 - UART_1 - Rx 232 signal to reader or FIM Module
Pin 4 - Power supply negative pole (GND)
J5: JST Connector to Kimaldi Optical Barrier
Pin 1 - Anode (+) of the emitting LED
Pin 2 - Cathode (-) of the emitting LED
Pin 3 - Collector (+) of the receiving phototransistor
Pin 4 - Emitter (GND) of the receiving phototransistor
J7 - Connector/socket for KiWi2 Converter (UART0):
Pin 1 - No Connect
Pin 2 - No Connect
Pin 3 - UART_0 - Tx 232 signal to Host
Pin 4 - UART_0 - Rx 232 signal to Host
Pin 5 - GND
Pin 6 - 5VDC input/output (only for KiWi2, BioMaxPlus-DB).
J10: Ethernet Connector (RJ45 connection)
