BioMax2 / KBio2-Online
Installation and Programming Manual
www.kimaldi.com Page 33 of 91
Table 3: Reader configuration codes
Tipo de lector
CFG_Serial_Port_XXX
a
a. CFG_Serial_Port_Reader corresponds to UART1 and CFG_Serial_Port_Host to UART0
Detalles
Communication with the
Host, Bio-OCX protocol
$90: 9600 baud
$91: 19200 baud
$92: 38400 baud
Only UART0 or
alternatively UART2
b
b. If UART2 is disabled, it automatically reconfigures to connect to the Host ($91), when UART0
is not configured for that role.
FIM module
c
/
RS-232 Online Reader
c. Configuration parameters related to FIM modules are typically set during the assembly process
and should not be modified. The FIM module typically connects to UART1.
$88: 9600 baud
$89: 19200 baud
$8A: 38400 baud
$8B: 57600 baud
Transparent frames, no
formatting considerations.
- UART0 up to 912 bytes
- UART1 up to 912 bytes
RS-232 Card Reader
(Automatic Mode)
$40: 9600 baud
$41: 19200 baud
CFG_Reader_Enable
d
must be enabled too
d. Recommended for readers with Automatic Mode (for instance, KRD13M or SC42). See chapter
7.2
and Subsection 8.1.4.
Omnikey 55xx Reader
(Automatic Mode)
$30: 9600 baud
$31: 19200 baud
CFG_Reader_Enable and
CFG_Multiread_TMO
e
must be configured too
e. Use with Omnikey 55xx Plug&Play RS-232. See chapter 7.2 and Subsection 8.1.4.
KRD13Mv2 Reader
(Online Mode)
$20: 9600 baud
$21: 19200 baud
$22: 38400 baud
Disable corresponding
UART on parameter
CFG_Reader_Enable
Serial-xR card $98: 9600 baud UART0 or UART1
KBio / BioMax $99: 19200 baud Only UART0 (912 bytes)
Communication to
BiomaxPlus-DB module
$D0: 9600 baud
$D1: 19200 baud
$D2: 38400 baud
$D3: 57600 baud
Only UART2
UART disabled $F0
