BioMax2 / KBio2-Online
Installation and Programming Manual
www.kimaldi.com Page 8 of 91
Optical Barrier: 4-pin connector for LED and phototransistor
1
.
Relay contact: 1 relay contact, normally open, 24V / 1A
Digital input: 1 relay-type digital input. In open circuit (contact open) its
logic value will be 0. In contact with GND (contact closed),
logic value 1.
Clock&Data Input: 1 port for Clock&Data reader, ABA-Track 2 encoding.
3.3. Addressing
BioMax2 and KBio2-Online electronics have two jumpers (JMP1 and JMP2) to encode
the ID Application in the KSP protocol.
See chapter 6.3.: “Routing and Localisation” for further details.
1. The LED optical barrier has been discontinued on devices featuring FIM5360 or equivalent.
See
section 5.3 for further information
