8.1.4. Card reading port configuration
Parameter$08: Reader Enable. Enables and configures the operation of the
Clock&Data ports.
Permitted values:
- Bit 0 (LSB): UART0 ON – card reader enabled in UART0. This also requires that
CFG_Serial_Port_Host is configured accordingly (e.g., with a value of $40;
refer to Tab le 3)
- Bit 1: UART1 ON – card reader enabled in UART1. This also requires that
CFG_Serial_Port_Reader is configured accordingly (e.g., with a value of $40;
refer to
Table 3)
- Bit 2: TTL_0 ON – Clock&Data TTL_0 enabled.
- Bit 3: TTL_1 ON – Clock&Data TTL_1 enabled.
- Bit 4: ‘$’before UART0 – ‘$’ is in front of the data received via UART0.
- Bit 5:
‘&’ before UART1 – ‘&’ is in front of the data received via UART1.
- Bit 6: ‘*’ before TTL_0 – ‘*’ is in front of the data received via TTL_0.
- Bit 7: ‘#’ before TTL_1 – ‘#’ is in front of the data received via TTL_1.
Default value:
- 0x8C: TTL_0, TTL_1 enabled; ‘#’ before TTL_1, TTL_0 without prefix.
Parameter$09: Buzzer on OK. Buzzer configuration for correct readings. We can
enable the buzzer assembled on the BioMax2 / KBio2-Online (internal), or a set of
external buzzer and green LED, so that they are enabled when a correct reading has
occurred.
Table 7: Card reading port configuration
Num Description
Def.
$08
CFG_Reader_
Enable
Enables RS-232 (UART0, UART1) and Clock&Data
(TTL_0, TTL_1) ports
$8C
$09
CFG_Reader_
BuzOK
Automatic activation of the Beeper after a correct
Clock&Data reading
$0C
$0A
CFG_Reader_
BuzError
Automatic activation of the Beeper after an incor-
rect Clock&Data reading
$0C
$0B
C F G _ R e a d e r _
Multiread
Multiread filtering $00
$0C
CFG_Multi-
read_TMO
Time-out in tenths of a second of the multiread
filtering to detect that a card has left the reading
field.
$28
