BioMax2 / KBio2-Online
Installation and Programming Manual
www.kimaldi.com Page 37 of 91
Permitted values:
- 0x00: This disables the optical barrier.
- 0x01 .. 0xFE: Delay value in tenths of second.
- 0xFF: Detect finger presence through the FIM module (Auto-ON).
Default value:
- 0xFF: Auto-On Finger Detection through FIM.
Legacy value:
- 0x80: This disables the optical barrier after 12.8 seconds without detecting the
beam (only for terminals with old FIM models and LED optical barrier).
Parameter$05: Optical Key Code. The presence of a finger blocking the optical
barrier will generate an event equivalent to a
Key Pressing. The key code is
configurable, although we recommend comparing finger presence to the pressing of
the green key. For this reason, the default value is 0x41 (corresponding to ‘A’).
Permitted values:
- 0x00 .. 0xFF: Any, although we recommend an alphanumerical value.
Default value:
- 0x41: ‘A’, is equivalent to the pressing of the green “Enter” key.
Parameter$1D: Main Reader. If a biometric FIM module is connected and Auto-On
Finger Detection must be enabled, we must configure this parameter.
Permitted values:
- 0x04, 0x05: Main FIM connected to UART0, UART1 (respectively).
- 0x00, 0xFF or other: Auto-On detection disabled.
Default value:
- 0x05: Main FIM connected to UART1 (typically, J7 connector on BioMax2).
Parameter$1E: Auxiliary Reader. If a second biometric FIM module is connected
and Auto-On Finger Detection must be enabled, we must configure this parameter.
Permitted values:
- 0x04, 0x05: Main FIM connected to UART0, UART1 (respectively).
- 0x00, 0xFF or other: Auto-On detection disabled.
Default value:
- 0x00: No Auxiliary FIM by default.
