9.6.21. Reception from UART
Function: Encapsulates a frame to be sent to the Host from the RS232 reader via the
UART of the BioMax2 / KBio2-Online electronics.
9.6.22. Optical Barrier Status
Function: If the path of the optical barrier is blocked for some time or there is
interference from an external light source, this is communicated through OpCode
0x4B.
When the situation returns to normal, the same OpCode with Arg =
0x0D indicates this.
See Subsection 5.3.2. and the explanation of the CFG-UI_OPT_T_WATCHDOG byte
for further details.
chapter 8
9.6.23. Enable optical barrier
Event
OP 0x83
NA 0x0001
ARG Byte 1: 0x02
Extra Data Frame that sends the RS232 reader to the Host
Event
OP 0x4B
NA 0x01
ARG Status code of the optical barrier
0x0D: Back to normal
0xED: Interference or blocking of the optical barrier
Instruction
OP 0x4A
NA 0x0000
ARG None
