BioMax2 / KBio2-Online
Installation and Programming Manual
www.kimaldi.com Page 62 of 91
Function: It returns a byte, showing the status of the four digital inputs (0 to 3). If the bit
is at 0, the input is in open circuit. If the bit is at 1, the input is shorted to GND.
If bit 4 of the CFG_ECHO is enabled (see Subsection 8.1.2.), the BioMax2 / KBio2-
Online electronics can notify of the change in the digital input status via an event with
the same OpCode.
9.6.17. Multiread filter status
Event
OP 0x60
NA 0x0001
ARG Bit 0: Status of DIN 0
Bit 1: Status of DIN 1
Bit 2: Status of DIN 2
Bit 3: Status of DIN 3
Instruction
OP 0x61
NA 0x0001
ARG Byte 1:
0: Status of UART_0 (only if it is configured as serial reader)
1: Status of UART_1 (only if it is configured as serial reader)
2: Status of TTL_0
3: Status of TTL_1
Response
OP 0x61
NA 0x0001 or >0x0001
ARG Byte 1: port from which the status is announced
Bytes 2 to <NA>: Code of the present card
