1.1.2. Presentation of the keypad and screen
1.1.3. Connection of the analyser
8 Introduction
T1 and T2
thermocouple
connections
C1 connection for external probes
(Pt100 temperature, CH
4
,...)
Flue gas probe connection
P- pressure tap
P+ pressure tap
Top view
Bottom view
Right side view
Measurements menu
Setting menu
Information menu
Function keys
OK button
ESC button
Customers menu
Procedures menu
Home screen
Directional arrows
ON/OFF button
Power supply
USB
connection
Light for battery
charging
Gas outlet
