Kinco FV20 Series User Manual

97
97
Function
code
Name
Descriptions
Unit
Factory
setting
Modif.
Setting
range
C2.21
Step 11 setting
Same as C2.01
1
000
○
0~323H
C2.22
Step 11 operating
time
0.0~6500.0
0.1
20.0
○
0~65000
C2.23
Step 12 setting
Same as C2.01
1
000
○
0~323H
C2.24
Step 12 operating
time
0.0~6500.0
0.1
20.0
○
0~65000
C2.25
Step 13 setting
Same as C2.01
1
000
○
0~323H
C2.26
Step 13 operating
time
0.0~6500.0
0.1
20.0
○
0~65000
C2.27
Step 14 setting
Same as C2.01
1
000
○
0~323H
C2.28
Step 14 operating
time
0.0~6500.0
0.1
20.0
○
0~65000
C2.29
Step 15 setting
Same as C2.01
1
000
○
0~323H
C2.30
Step 15 operating
time
0.0~6500.0
0.1
20.0
○
0~65000
Group C3：textile swing function
C3.00
Tex tile function
selection
0
：
Not choose textile function
1
：
Select textile function
1
0
X
0~1
C3.01
Swing frequency
operation
LED unit position
：
starting mode
0
：
automatic
1
：
terminal manual
LED ten position
：
swing control
0
：
Relative center frequency
1
：
Relative maximum frequency
LED hundreds
：
Swing frequency
Status memory
0
：
shutdown memory
1
：
stop without memory
LED thousands
：
Swing frequency
status power down storage
0
：
storage
1
：
not stored
C3.02
Swing frequency
preset frequency
0.00Hz~upper limit frequency
0.01Hz
0.00Hz
○
0~30000
C3.03
Swing frequency
preset frequency
waiting time
0.0~3600.0s
0.1s
0.0s
○
0~36000
C3.04
Swing frequency
amplitude
0.0%~50.0%
0.1%
0.0%
○
0~500
C3.05
Mutation frequency
0.0%~50.0%
0.1%
0.0%
○
0~500
C3.06
Wobble cycle
0.1~999.9s
0.1s
10.0s
○
1~9999
C3.07
Triangle wave rise
time
0.0%~100.0%(refer to the swing
frequency period)
0.1%
50.0%
○
0~1000
Group d0：Status display
d0.00
Main reference
frequency
-300.00~300.00Hz
0.01Hz
0.00
*
0~60000
d0.01
Auxiliary reference
frequency
-300.00~300.00Hz
0.01Hz
0.00
*
0~60000
d0.02
Preset frequency
-300.00~300.00Hz
0.01Hz
0.00
*
0~60000
