Kinco FV20 Series User Manual

98
98
Function
code
Name
Descriptions
Unit
Factory
setting
Modif.
Setting
range
d0.03
Frequency after
Acc/Dec
-300.00~300.00Hz
0.01Hz
0.00
*
0~60000
d0.04
Output frequency
-300.00~300.00Hz
0.01Hz
0.00
*
0~60000
d0.05
Output voltage
0~480V
1V
0
*
0~480
d0.06
Output current
0.0~3Ie
0.1A
0.0
*
0~65535
d0.07
Torque current
-300.0~+300.0%
0.1%
0.0%
*
0~6000
d0.08
Magnetic flux
current
0~+100.0%
0.1%
0.0%
*
0~1000
d0.09
Motor power
0.0~200.0%（Corresponding to the
motor’s rated power）
0.1%
0.0%
*
0~2000
d0.10
Motor estimated
frequency
-300.00~300.00Hz
0.01
0.00
*
0~60000
d0.11
Motor actual
frequency
-300.00~300.00Hz
0.01
0.00
*
0~60000
d0.12
Bus voltage
0~800V
1V
0
*
0~800
d0.13
Drive operation
status
0~FFFH
bit0：Run/Stop
bit1：Reverse/Forward
bit2：Operating at zero
frequency
bit3：Accelerating
bit4：Decelerating
bit5：Operating at constant
speed
bit6：Pre-commutation
bit7：Tuning
bit8：Over-current limiting
bit9：DC over-voltage limiting
bit10：Torque limiting
bit11：Speed limiting
bit12：Drive fault
bit13：Speed control
bit14：Torque control
bit15：Position control(Reserved)
1
0
*
0~FFFF
H
d0.14
Input terminals
status
0~FFH，
0：OFF；1：ON
1
00
*
0~FFH
d0.15
Output terminals
status
0~1FH，
0：OFF；1：ON
1
0
*
0~1FH
d0.16
AI1 input
-10.00~10.00V
0.01V
0.00
*
0~2000
d0.17
AI2 input
-10.00~10.00V
0.01V
0.00
*
0~2000
d0.18
Keyboard
potentiometer input
-10.00~10.00V
0.01V
0.00
*
0~2000
d0.19
Percentage of AI1
after regulation
-100.00%~110.00%
0.01%
0.00
*
0~20000
d0.20
Percentage of AI2
after regulation
-100.00%~110.00%
0.01%
0.00
*
0~20000
d0.21
Percentage of
Keyboard
potentiometer
after regulation
-100.00%~110.00%
0.01%
0.00
*
0~20000
