Kinco FV20 Series User Manual

78
78
Function
code
Name
Descriptions
Unit
Factory
setting
Modif.
Setting
range
Ten’s place of LED：
0：Hold reference frequency at
stop
1：Clear reference frequency at
stop
Hundred’s place of LED：
0： UP/DN integral time valid
1： UP/DN speed value
A2.04
Jog operating
frequency
0.10~50.00Hz
0.01Hz
5.00
○
10~5000
A2.05
Interval of Jog
operation
0.0~100.0s
0.1s
0.0
○
0~1000
A2.06
Skip frequency 1
0.00~300.00Hz
0.01Hz
0.00
×
0~30000
A2.07
Range of skip
frequency 1
0.00~30.00Hz
0.01Hz
0.00
×
0~3000
A2.08
Skip frequency 2
0.00~300.00Hz
0.01Hz
0.00
×
0~30000
A2.09
Range of skip
frequency
0.00~30.00Hz
0.01Hz
0.00
×
0~3000
A2.10
Skip frequency 3
0.00~300.00Hz
0.01Hz
0.00
×
0~30000
A2.11
Range of skip
frequency 3
0.00~30.00Hz
0.01Hz
0.00
×
0~3000
Group A3：Setting curve
A3.00
Reference
frequency curve
selection
LED unit’s place：
AI1 curve selection
0：Curve 1
1：Curve 2
2：Curve 3
3：Curve 4
LED ten’s place：
AI2 curve selection
0：Curve 1
1：Curve 2
2：Curve 3
3：Curve 4
LED hundred’s place：Keyboard
potentiometer curve selection
0：Curve 1
1：Curve 2
2：Curve 3
3：Curve 4
LED thousand’s place：
Pulse input curve selection
0：Curve 1
1：Curve 2
2：Curve 3
3：Curve 4
1
0000
○
0~3333H
A3.01
Max reference of
curve 1
A3.03~110.00%
0.01%
100.00%
○
0~11000
A3.02
Actual value corres-
ponding to the Max
reference of curve 1
Reference frequency：
0.0~100.00% Fmax
Torque：0.0~300.00%Te
0.01%
100.00%
○
0~10000
