80
80
Function
code
Name
Descriptions
Unit
Factory
setting
Modif.
Setting
range
A3.19
Min reference of
curve 4
0.0%~A3.17
0.01%
0.00%
0~11000
A3.20
Actual value
Corresponding to
the Min reference of
curve 4
The same as A3.02
0.01%
0.00%
0~10000
A3.21
Characteristic
selection of curve
LED unit’s place:Characteristic
choice of curve 1
0:set 0 Hz when frequency < 0
Hz
1:symmetrical about origin
2:absolute value
LED unit’s place: Characteristic
choice of curve 2
0:set 0 Hz when frequency < 0
Hz
1:symmetrical about origin
2:absolute value
LED hundred’s place:
Characteristic choice of curve 3
0:set 0 Hz when frequency < 0
Hz
1:symmetrical about origin
2:absolute value
LED thousand’s place:
Characteristic choice of curve 4
0:set 0 Hz when frequency < 0
Hz
1:symmetrical about origin
2:absolute value
1
0000
0000~
2222H
【0000】
Group A4:Acc/Dec parameters
A4.00
Acc/Dec mode
0:Linear Acc/Dec
1:S curve
1
0
×
0~1
A4.01
Acc time 2
0.0~6000.0
0.1s
20.0s
0~60000
A4.02
Dec time 2
0.0~6000.0
0.1s
20.0s
0~60000
A4.03
Acc time 3
0.0~6000.0
0.1s
20.0s
0~60000
A4.04
Dec time 3
0.0~6000.0
0.1s
20.0s
0~60000
A4.05
Acc time 4
0.0~6000.0
0.1s
20.0s
0~60000
A4.06
Dec time 4
0.0~6000.0
0.1s
20.0s
0~60000
A4.07
S curve acceleration
starting time
10.0%~50.0%(Acc time)
A4.07+ A4.08≤90%
0.1%
20.0%
100~500
A4.08
S curve acceleration
ending time
10.0%~70.0%(Acc time)
A4.07+ A4.08≤90%
0.1%
20.0%
100~700
A4.09
S curve deceleration
starting time
10.0%~50.0%(Dec time)
A4.09+ A4.10≤90%
0.1%
20.0%
100~500
A4.10
S curvede celeration
ending time
10.0%~70.0%(Dec time)
A4.09+ A4.10≤90%
0.1%
20.0%
100~700
A4.11~
A4.21
Reserved
-
-
-
-
-
