Kinco FV20 Series User Manual

81
81
Function
code
Name
Descriptions
Unit
Factory
setting
Modif.
Setting
range
A4.22
A4.22 Switch
frequency for
Acc/Dec time 1 and
Acc/Dec time 2.
0.00~300.00Hz【000.00】
Acc/Dec time 2 is selected when
output frequency is less than A4.22
0.01Hz
0.00Hz
×
0~30000
A4.23~
A4.25
Reserved
-
-
-
-
-
Group A5：Control parameters
A5.00
Speed/torque
control mode
0：Speed control mode
1：Torque control mode
1
0
×
0~1
A5.01
ASR1-P
0.1~200.0
0.1
20.0
○
1~2000
A5.02
ASR1-I
0.000~10.000s
0.001s
0.200s
○
0~10000
A5.03
ASR1 output filter
0~8(Corresponding to
0~2^8/10ms）
1
0
○
0~8
A5.04
ASR2-P
0.1~200.0
0.1
20.0
○
1~2000
A5.05
ASR2-I
0.000~10.000s
0.001s
0.200s
○
0~10000
A5.06
ASR2 output filter
0~8（Corresponding to
0~2^8/12.5ms）
1
0
○
0~8
A5.07
ASR1/2 switching
frequency
0.0%~100.0%
0.1
10.0％
○
0~1000
A5.08
Maximum speed
limit for forward
running when
torque control
0.0%~+100.0%
0.1％
100.0％
○
0~1000
A5.09
Maximum speed
limit for reverse
running when
torque control
0.0%~+100.0%
0.1％
100.0％
○
0~1000
A5.10
Driving torque limit
0.0%~+300.0%
0.1%
180.0%
○
0~3000
A5.11
Braking torque limit
0.0%~+300.0%
0.1%
180.0%
○
0~3000
A5.12
Reference torque
selection
0：Digital setting
1：AI1
2：AI2
3：Keyboard potentiometer
4：Pulse DI terminal setting
1
0
×
0~4
A5.13
Digital reference
torque
-300.0%~+300.0%
0.1%
0.0%
○
0~6000
A5.14
Speed→Torque
switching point
0%~+300.0% Initial torque
0.1%
100.0%
×
0~3000
A5.15
Speed/torque
switching delay time
0~1000ms
1
0
×
0~1000
A5.16
Reference torque
filtering time
0~65535ms
1ms
0
×
0~65535
A5.17
ACR-P
1~5000
1
1000
○
1~5000
A5.18
ACR-I
0.5~100.0ms
0.1
8.0
○
5~1000
Group A6：Control terminals parameters
A6.00~
A6.06
Multi-function
terminal X1~X6
0：No function
1：Forward
2：Reverse
3：Forward jog operation
1
0
×
0~47
