91
91
Function
code
Name
Descriptions
Unit
Factory
setting
Modif.
Setting
range
Group b3:Communication parameter
b3.00
Communication
configuration
Unit’s place of LED: Baud rate
selection
0:4800BPS
1:9600BPS
2:19200BPS
3:38400BPS
4:115200BPS
5:125000BPS
Ten’s place of LED: Data format
0:1-8-2-N format,RTU
1:1-8-1-E format,RTU
2:1-8-1-O format, RTU
3:1-7-2-N format,ASCII
4:1-7-1-E format,ASCII
5:1-7-1-O format,ASCII
Hundred’s place of LED wiring
mode
0:Direct connection via cable
(RS232/485)
1: MODEM (RS232)
1
001
×
0~155H
b3.01
Local address
0~127,0 is the broadcasting
address
1
5
×
0~127
b3.02
Time threshold for
judging the com-
munication status
0.0~1000.0s
0.1
0.0s
×
0~10000
b3.03
Delay for responding
to control PC
0~1000ms
1
5ms
×
0~1000
b3.04~
b3.11
Reserved
Reserved
-
-
-
-
Group b4:Keyboard parameters
b4.00
Key-lock function
selection
0: The keys on the operation
panel are not locked, and all the
keys are usable.
1: The keys on the operation
panel are locked, and all the keys
are unusable.
2: All the keys except for the
multi-functional key are unusable.
3: All the keys except for the
SHIFT key are unusable.
4:All the keys except for the RUN
AND STOP keys are unusable.
1
0
0~4
b4.01
Multi-function key
definition
0: Jog function
1: Coast-to-stop
2: Stop in shortest time
3: Switch of input method of
operating command
4:Switch forward/reverse.(Save
after power failure)
5: Switch forward/reverse.(Not
save after power failure)
1
0
0~3
