CK2810 / CK3010H
3
-
8
IMPLEMENT LIMITATIONS
STANDARD SIZE BY IMPLEMENT
mm (in.)
IMPLEMENT DESCRPITION CK2810 CK3010H REMARKS
1. Loader Max. Bucket width 1,219 (48.0), 1,372 (54.0) Operating Capa.300kg.f (660lbs) and below
2. Backhoe with sub frame Max. Digging depth Below 1,956 (77.0) Do not use 3 point hitch backhoe
3. Mid Mower Max. width Below 1,524 (60.0)
4. Tiller Max. width Below 1,194 (47.0)
5. Box Blade Max. width Below 1,219 (48.0)
6. Rear Blade Max. width Below 1,524 (60.0)
7. Rotary Cutter Max. width 1,321 (52.0), 1,524 (56.0)
8. Belt Guard Max. width 1,321 (52.0), 1,524 (60.0)
9. Chain Guard Max. width 1,321 (52.0), 1,524 (60.0)
10. Bale Transport Max. Below 1,219 (48.0)
11. Core Aerator Max. 1,219 (48.0), 1,524 (60.0)
