1. Make sure to link the left and right
brake pedals as shown in the g-
ure while driving on a road. The
tractor can roll over if depressing
only one brake pedal at a high
speed.
2. To make a sharp turn in a work
field, disengage the left and right
brake pedals to use one brake
pedal. Unlock the brake lock, and
then turn the steering wheel while
depressing the brake pedal on the
turning side.
PARKING BRAKE LEVER
HST TYPE
Leaving transmission in gear
with the engine stopped will
not prevent tractor from rolling.
Park on level ground whenever
possible.
Always lock the parking brake.
•
•
CAUTION
To avoid personal injury:
Always set the parking brake and
stop the engine before leaving
the tractor seat.
When parking the vehicle on a
hill, position the shift lever in
low forward (1st gear) for up-
hill and low reverse (1st gear)
for downhill. Set the parking
brake and chock the wheels.
•
•
CAUTION
(1) Foot Parking Brake Lever
(2) Brake Pedal (3) Pedal Interlock
(A) Depressing (B) Pressing Down
M56O445B
To Next Page
