Pressurized diesel fuel or hy-
draulic fluid may be sprayed
on your skin or eyes, lead-
ing to a severe injury or even
death.
To check leakage, use a board
and wear protective gloves
and goggles.
If your eyes come into contact
with the hydraulic fluid, seek
medical attention immediately.
Never try to disconnect the
tube and quick coupler while
the tractor and implement are
in operation. Release the pres-
sure by operating the lever
after the engine is stopped.
•
•
•
•
WARNING
JOYSTICK VALVE
M56O428A
G : Boom Up E : Bucket Up (Roll back)
H : Boom Down F : Bucket Down (Dump)
Hoses and couplers for instal-
lation of the loader are supplied
together with the loader.
•
NOTE
PORT DIRECTION FUNCTION
E
Bucket
Up
F
Bucket
Down
G
Boom
Up
H
Boom
Down
