PRECAUTION AT OVERHEATING
Take the following actions in the
event the coolant temperature be
nearly or more than the boiling point,
what is called "Overheating"
1. Stop the machine operation in a
safe place and keep the engine
unloaded idling.
2. Don't stop the engine suddenly,
but stop it after about 5 minutes of
unloaded idling.
3. Keep yourself well away from the
machine for 10 minutes or while
the steam blown out.
4. Checking that there is no danger
of burn, get rid of the causes of
overheating according to the man-
ual, see "Troubleshooting" section,
and then, start the engine again.
(1) Power Steering Line
CHECKING POWER STEERING
LINE
1. Check to see that all hydraulic
lines and hose clamps are tight
and undamaged.
2. If damage is found, replace the
hose or clamp at once.
621Oa29a
(A) Wheel - to - wheel distance at rear
(B) Wheel - to - wheel distance at front
ADJUSTING TOE-IN
1. Park tractor on a at place.
2. Turn steering wheel so front wheels
are in the straight ahead position.
3. Lower the implement, lock the
parking brake and stop the engine.
4. Measure distance between tire
beads (center) at front of tire, hub
height.
5. Measure distance between tire
beads at rear of tire, hub height.
6. Front distance should be 2 ~ 8 mm
less than rear distance. If not, ad-
just tie rod length.
621Oa30a
