EVERY 400 HOURS
CHANGING TRANSMISSION
FLUID
(1) Tie Rod (2) Lock Nut
ADJUSTING PROCEDURE
1. Loosen the lock nut and turn the
turnbuckle to adjust the rod length
until the proper toe-in measure-
ment is obtained.
2. Retighten the lock nut.
See "Initial 50 hours" in page 10-15.
REPLACING FUEL FILTER
ELEMENT
(See "Cleaning fuel filter" in every
100 hours maintenance.)
CHANGING FRONT AXLE
CASE OIL
See "Initial 50 hours" in page 10-16.
621Oa31a
EVERY 600 HOURS
ADJUSTING FRONT AXLE PIVOT
If the front axle pivot pin adjustment
is not correct, front wheel vibration
can occur causing vibration in the
steering wheel.
ADJUSTING PROCEDURE
Loosen the lock nut, tighten the ad-
justing screw all the way, and then
loosen the screw by 1/6 turn. Re-
tighten the lock nut.
621Oa32a
(1) Adjusting Screw (2) Lock Nut
To Next Page
