621O520A
(1) Main Gear Shift Lever
(2) Shuttle Shift Lever
(3) Range Gear Shift Lever (Hi-Lo)
(4) Front Wheel Drive Lever
(N) Neutral Position
“HIGH”
“LOW”
“2WD”
“4WD”
- FORWARD
- REVERSE
6. SELECTING THE TRAVEL SPEED.
(1) MAIN SHIFT LEVER
The main shift is fully synchronized
to shift without stopping just by de-
pressing the clutch pedal.
(2) SHUTTLE SHIFT LEVER
Push forward or pull backward to se-
lect forward or reverse. The direc-
tion of travel can be changed without
changing the main shift.
(3) HI-LOW SHIFT LEVER
it is difficult to shift the range gear,
take the following actions.
1) Be sure the range gear shift lever
is in neutral position.
2) Release clutch pedal.
3) Release the speed control pedal
to neutral.
4) Depress clutch pedal and then
shift the range gear shift lever.
IMPORTANT
To avoid transmission dam-
age, depress clutch pedal and
stop tractor before shifting be-
tween ranges.
