8.2 Technical Data for Type 9287C
Range F
x
, F
y
F
z
kN
kN
–10 ... 10
–10 ... 20
Overload F
x
, F
y
F
z
kN
kN
–13/13
–10/25
Calibrated range F
x
, F
y
F
z
kN
kN
0 ... 10
0 ... 20
Calibrated partial range F
x
, F
y
F
z
kN
kN
0 ... 1
0 ... 2
Threshold N <0,05
Sensitivity (nominal) F
x
, F
y
F
z
pC/N
pC/N
–7,5
–3,8
Sensitivity deviation F
x
, F
y
F
z
%
%
±1 ±2
±1 ±2
Linearity (full range + partial range)
typical
%FSO
%FSO
±0,2
±0,1
Hysteresis (full range + partial range)
typical
%FSO
%FSO
<0,3
0,1
Crosstalk F
x
–> F
y
F
x
–> F
z
F
y
–> F
x
F
y
–> F
z
F
z
–> F
x
F
z
–> F
y
%
%
%
%
%
%
±1,5
±1,5
±1,5
±1,5
±0,5 ±1,0

±0,5 ±1,0
Natural frequency x-axis
y-axis
z-axis
Hz
Hz
Hz
750
780
520
Center of Pressure error (COP)
without correction
dax
day
mm
mm
±15 ±25
(s. chapter 8.3)
±15 ±3
0
(s. chapter 8.3)
Satisfies the ä standards (73/23/EG) for electrical equipment and systems according to the attached
declaration of conformity.
Values in parenthesis { } apply to the area outside the sensor rectangle (420x700 mm).
Pag
e 30 9287C_002-462e-03.11
