Assembly, Installation and Putting Into Operation
4.2 Basic Circuitry and Cabling of the Measuring System
The electric charges (in pC) yielded by the force plate are
converted by charge amplifiers into proportional voltages,
which in turn can be displayed, recorded or further proc-
essed using appropriate equipment.
The following rules should be observed when cabling the
measuring rig:
Between force plate and charge amplifier the special
cables supplied by Kistler must be used
Ordinary cables may be used to link the charge amplifi-
ers with the display or evaluation instruments
Make sure that all work with electrical connections is
done carefully and with cleanliness. Remove the protec-
tive caps from the connections only immediately before
connecting a cable
According to safety requirements the following has to be
observed:
The force plate has to be connected to earth using the
Potential Equalization Conductor provided in the scope
of delivery to meet the ä-standards regarding Earth
Leakage Current.
The data acquisition computer and persons who are in
direct contact with it have to remain in a distance of
1,5 m from the patient at all times for the same reason.
9287C
_002-462e-03.11 Page 13
