Technical Data
8.3.2 Mechanical and Environment
Distance of force plate surface from x-, y-plane
Distance of sensor axis from y-axis
Distance of sensor axis from x-axis
a
z0
a
b
mm
mm
mm
–52
210
350
Tightening torque of fastening screws M12x25 N·m 90
Weight (without mounting frame) kg 25
Surface pressure N/mm
2
5
(s. chapter 5.7)
Material:
Top plate
Feet + prestress elements
Aluminum sandwich construc-
tion
Stainless steel
Degree of protection (DIN 40050) IP65 (splash proof)
Operating temperature range °C 0 … 60
8.3.3 Electrical
Supply voltage VDC 10 … 30
Supply current mA
45
Output voltage V 0 ... ±5
Output current mA –2 ... 2
Output resistance
10
Output noise mV
pp
<5
Digital input High = 1 (optocouplers) V
mA
5 … 45
0,4 … 4,4
Digital input Low = 0 V 0 or open
9287C
_002-462e-03.11 Page 33
