86 86 V V 1.01.0





Service ManualService Manual

Operating Lights marLEDOperating Lights marLED

®®

E9 / E9i / E15E9 / E9i / E15

00 88

h) Checking the sliding / h) Checking the sliding / plug-in contacts of the tracking armsplug-in contacts of the tracking arms

1, 1, 2 2 PE PE (GNYE)(GNYE)

3 3 +VDC +VDC (RD)(RD)

4 4 -VDC -VDC (BU)(BU)

5 5 CAN+ CAN+ (WH)(WH)

6 6 CAN– CAN– (BN)(BN)

7 7 Video Video Y, Y, shieldshield

8 8 Video Video Y, Y, signal signal (WH)(WH)

9 9 Video Video C, C, shieldshield

10 10 Video Video C, C, signal signal (BN)(BN)

Fig. Fig. 10-13 10-13 Contact Contact block, block, 9-pole, 9-pole, for for operating operating light light with with wall wall control control panel panel and and camera camera or or TFTTFT

••



Apply some contact spray to the Apply some contact spray to the contact springs inside the slip-ring contact block whilecontact springs inside the slip-ring contact block while

rotating the tracking arm 360 degrees.rotating the tracking arm 360 degrees.

••

 Check the cables at the Check the cables at the plug-in contacts.plug-in contacts.

••

 √√
