Sensor cables
HSO-9001 Cable: Ethernet, 50 foot
HSO-9011 Cable: Ethernet, 50 foot, Plenum Rated
Surge suppressors
KMD-5567 EIA-485 surge suppressor for MS/TPnetworks
Replacement parts
HPO-0054 Replacement bulbs
HPO-0063 Replacement two-pin jumper
Dual duct actuator
TSP-8001 VAV actuator with airflow inputs (required for dual duct)
Airflow sensors
For VAV terminal units without airflow pickup tubes, order one of the following sensors.
SSS-1012 3-5/32 in. length (80 mm)
SSS-1013 5-13/32 in. length (137 mm)
SSS-1014 7-21-32 in. length (195 mm)
SSS-1015 9-29/32 in. length (252 mm)
KIT-8001 A 3-5/32 inch sensor and 3 feet of FR tubing
Available models
The following is a list of SimplyVAV available models.
Description Models
BACnet ASC: VAV Cooling/Heating only, 40 in-lbs, 90second actuator BAC-8001
BACnet ASC: VAV Fan and Reheat, 40 in-lbs, 90second actuator BAC-8005
BACnet ASC: VAV Dual Duct, 40 in-lbs, 90second actuator BAC-8007
BACnet ASC: VAV Fan and Reheat, True damper position, 40 in-lbs, 60
second actuator
BAC-8205
Safety considerations
KMC Controls assumes the responsibility for providing you a safe product and safety
guidelines during its use. Safety means protection to all individuals who install, operate, and
service the equipment as well as protection of the equipment itself. To promote safety, we
use hazard alert labeling in this manual. Follow the associated guidelines to avoid hazards.
Section 1: About the controllers KMC Controls, Inc.
10 Revision H
