Dual-duct application
The dual-duct application is for a BAC-8007 controller. Dual-duct VAV requires a TSP-8001
actuator to be used with the BC-8007 as shown in the illustration Dual-duct wiring
diagram on page 47.
Submittal sheets for several variations of this application are available from the BAC-8000
series page at KMCControls.com.
Illustration 6–6 Dual-duct wiring diagram
ON CTS
1 2
COMM
READY
AI1
AI5
GND
AO4
AO3
SC
BO8
BO5
BO6
SC
BO7
24VAC
AI6
GND
AI7
T-STAT/ SENSOR
-A
+B
S
EOL
BACnet MS/TP
P2
CW
COM
P1
CCW
24VAC
P OUT
MOTOR
F.B. POT
24 VAC
BAC-8007
TSP-8001
SimplyVAV Section 6: Application drawings
Revision H 47
