Value objects
BACnet value objects represent setpoints or other operational conditions in the controller.
Note: Not all objects are present in every model.
Object Name Description
AV1 SPACE TEMP Space Temperature
AV2 STPT OFFSET Setpoint Offset
AV3 ACT COOL STPT Active Cooling Setpoint
AV4 ACT HEAT STPT Active Heating Setpoint
AV5 OCC CL STPT Occupied Cooling Setpoint
AV6 OCC HT SPT Occupied Heating Setpoint
AV7 UNOCC CL STPT Unoccupied Cooling Setpoint
AV8 UNOCC HT STPT Unoccupied Heating Setpoint
AV9 MIN CL STPT Minimum Cooling Setpoint
AV10 MAX HT STPT Maximum Heating Setpoint
AV11 MIN STPT DIFF Minimum Setpoint Differential
AV12 STBY OFFSET Standby Offset
AV13 MIN COOL FLOW Minimum Cooling Flow
AV14 MAX COOL FLOW Maximum Cooling Flow
AV15 MIN HEAT FLOW Minimum Heating Flow
AV16 MAX HEAT FLOW Maximum Heating Flow
AV17 AUXILIARY FLOW Auxiliary Flow
AV18 PRI K FACT Primary K Factor
AV19 PRI CORR SLOPE Primary Correction Slope
AV20 PRI CORR OFFST Primary Correction Offset
AV21 PRI LO FLOW CORR Primary Low Flow Correction
AV22 PRI FLOW STPT Primary Flow Setpoint
AV23 PRI RAW FLOW Primary Raw Flow
AV24 PRI ACTUAL FLOW Primary Actual Flow
AV32 MIN FAN SPEED Minimum Fan Speed
AV33 MAX FAN SPEED Maximum Fan Speed
Table 8–4 Analog value objects
Section 8: System integration and networking KMC Controls, Inc.
68 Revision H
