BAC-8007 Model BAC-8007 is supplied with inputs, outputs, and sequences of operation for
the following functions.
l Dual-duct VAV heating and cooling
l Occupancy setback—requires STE-8201
l System diagnostic indicators
l Airflow balancing
Additional topics in this section
Specifications 6
Accessories and replacement parts 9
Available models 10
Safety considerations 10
Specifications
SimplyVAV controller specifications are subject to change without notice.
Inputs and outputs
All inputs and outputs are factory programmed and application specific. No field
configuration is required. For details on input and output connections, see the topic
Application drawings on page 41. For a detailed listing of input and output objects, see the
topic BACnet objects on page 67.
Analog inputs
Analog inputs represent BACnet analog input. Not all input are applicable or required for all
models.
Key features Standard units of measure.
Overvoltage input protection
Connectors RJ-45 room sensor jack
Screw terminals for wire sizes 12-26 AWG
Conversion 12–bit analog–to–digital conversion
Input range Passive, 10 kΩ pull-up to 3.3 volts DC
Analog outputs
Analog outputs are configured to represent BACnet analog output objects. No field
configuration is required. For details on application specific output connections see the
section Application drawings on page 41.
Key features Output short protection
Standard units of measure
Connector Screw terminals for wire size 12-26AWG
Conversion 12–bit digital-to-analog conversion
Output voltage 0–10 VDC
Output current 30 mA per output, 30 mA total for all analog outputs
Section 1: About the controllers KMC Controls, Inc.
6 Revision H
