BACnet objects
The SimplyVAV controllers are BACnet Application Specific Controller (ASC) that are
composed of standard BACnet objects. This section lists the objects that are likely to be
monitored by a standard BACnet operator workstation to verify system operation.
Caution
Changing the configuration of any object may result in
unpredictable operation of a controller and damage to
equipment that is under control of a SimplyVAV controller.
Input objects
The following BACnet input objects represent values at the physical inputs of the controller.
For wiring details, see the topic Application drawings on page 41.
Input Name Description Object type Termination
AI1 DISCHARGE AIR Discharge Air Temperature KMC 10K Type_III 10Kfixed
AI2 SPACE SENSOR Space Sensor KMC Type II Deg F 10Kfixed
AI3 SETPOINT OFFSET Setpoint Offset TABLE 4 10Kfixed
AI4 PRIMARY DUCT Primary Duct Pressure
AI5 SECONDARY DUCT Secondary Duct Pressure
Table 8–2 Input objects
Output objects
The following BACnet output objects represent values at the physical outputs of the
controller. For application specific output wiring details, see the topic Application
drawings on page 41.
Output Name Description Units
AO3 ANALOG HEAT Analog Heat 0_100%
AO4 FAN SPEED Fan Speed 0_100%
BO1 DAMPER CW Damper Clockwise
BO2 DAMPER CCW Damper Counter Clockwise
BO5 FAN Fan
BO6 HT STAGE 1 Heating Stage 1
BO7 HT STAGE 2 Heating Stage 2
BO8 HT STAGE 3 Heating Stage3
Table 8–3 Output objects
SimplyVAV Section 8: System integration and networking
Revision H 67
