KMC Controls SimplyVAV BAC-8001 User Manual

Object Name Description
BV12 BALANCE MODE Balance Mode
BV13 DAT SENSOR DAT Sensor Present
BV14 PRI BAL TRIGGER Primary Balance Trigger
Binary value objcts (continued)
Object Name Description
MSV1 OCCUPIED MODE Occupied Mode
MSV2 FAN CONFIG Fantype Configuration
MSV3 REHEAT Reheat Type
MSV6 WALL SENSOR Multi-state Value #6
Table 8–6 Multistate value objects
Loop objects
BACnet PID loops are used for modulating the damper and controlling reheat.
Loop Name Description
LOOP1 CL LOOP Cooling Loop
LOOP2 HT LOOP Heating Loop
LOOP3 DAT Loop Discharge Air Temp Loop
Table 8–7 PID control loop objects
Section 8: System integration and networking KMC Controls, Inc.
70 Revision H
