KMC Controls SimplyVAV BAC-8001 User Manual

Binary outputs
Binary outputs are configured to represent BACnet binary output objects. No field
configuration is required. For details on application specific output connections see the
section Application drawings on page 41.
Key features Optically isolated triac output
Connector Screw terminals for wire size 12-26 AWG
Output range Maximum switching 24 Volts AC
1 ampere per external output, 3 amperes total
Communications—BACnet MS/TP
l EIA–485 operating at rates up to 76.8 kilobaud.
l Removable screw terminal block.
l Wire size 12-26AWG
l Switch selected end of line termination
Memory
l Programs and program parameters are stored in nonvolatile memory.
l Auto restart on power failure
Air flow sensor features
l Configured as BACnet analog input object.
l CMOS differential pressure 0-2 inches of water (0-500 Pa) measurement range.
Internally linearized and temperature compensated.
l Span accuracy 4.5% of reading.
l Zero point accuracy 0.0008 in. H2O/0.2 Pa at 25° C
l Barbed connections for 1/4 inch FR tubing.
Actuator specifications
Torque 40 in-lb. (4.5 N
•
m)
Angular rotation 0 to 95°
Adjustable end stops at 45° and 60° rotation
Motor timing
BAC-8001, BAC-8005,
BAC-8007
90 sec./90° at 60 Hz
108 sec./90° at 50 Hz
Motor timing
BAC-8205
60 sec./90° at 60 Hz
Shaft size Directly mounts on 3/8 to 5/8inch (9.5to16mm) round or 3/8
to 7/16 inch (9.5to11 mm) square damper shafts.
SimplyVAV Section 1: About the controllers
Revision H 7
