Section 11
Parts List
20425652
5-2005/Rev 0
11-12
Table 11-5
Hydraulic Piston Assembly
05132253
Item
Part
Number
Description
Quantity
1 05132261 Hydraulic Ram Piston, 4.03 1
2 05074380 Plunger Retainer Pin, Clevis, 0.25 x 0.43 12
3 05049887 Set Screw, Socket, 3/8-16 x 3/8 2
4 10148757 Check Valve Cartridge W/O-Ring 2
5 49877509 Adhesive, Thread Locker --
6 05088364 Flat Snap Ring, 0.032 x 0.375 x 2.010 2
7 05049994 Backup Ring, 1.50 x 1.25 2
8 05087713 O-Ring, 1-1/4 x 1-1/2 x 1/8 2
9 05117965 Seal Assembly, Hydraulic Piston 1
10 05117940 Bearing Ring, Hydraulic Piston 2
05115951 Rebuild Kit
Includes Items 4, 6, 7, 8,9 and 10
To Next Page
