20479304
2-2012/Rev 04
10-1
SECTION 10
SPECIFICATIONS
10.1 Overview
Comprehensive listings of specifications for the Streamline S50 are provided in this section.
Table 10-1
Model
Motor Horsepower
Rating
HP Kw
S50 50 37
10.2 Installation Specifications
Environment
Installation location Indoors
Air borne dust/contaminants Minimal
Ambient temperature
Minimum storage
36 F (2 C)
Minimum operating
40 F (5 C)
Maximum operating
104 F (40 C)
Maximum relative humidity*
(at maximum operating temperature)
95%
*Note: When the relative humidity is above 50%, the oil in the reservoir
should be checked frequently for water content.
Equipment Dimensions and Weights
Length Width Height Weight
85.37” (2,168 mm) 39.36” (1,000 mm) 43.06” (1,094 mm) 2,590 lbs (1,175 kg) (air-to-oil)
2,194 lbs (995 kg) (water-to-oil)
