Section 10
Specifications
20479304
2-2012/Rev 04
10-6
10.4 Electrical Specifications
Electrical System
Motor type TEFC (Totally Enclosed Fan Cooled)
Ampacity and Power Voltage Requirements
Power Voltage
Motor
Horsepower
Full Load
Amps
Circuit Breaker
Amps
200/3/50-60 50 132 175
208/3/50-60 50 128 175
240/3/60 50 112 175
380/3/50 50 69 100
400/3/50 50 66 100
415/3/50 50 64 100
480/3/60 50 56 80
575/3/60 50 47 80
10.5 Hydraulic and High Pressure Water System Specifications
Hydraulic System
Maximum operating pressure 3,000 psi (207 bar)
Main system relief valve 3,407 psi (235 bar)
High Pressure Water System
Maximum flow rate at given deadhead pressure
55,000 psi (3,792 bar) 0.95 gpm (3.6 L/min)
60,000 psi (4,137 bar) 0.86 gpm (3.3 L/min)
Plunger diameter 0.875” (22 mm)
Piston diameter 4.03” (102.4 mm)
Intensification ratio 20:1
Minimum outlet pressure 5,800 psi (400 bar)
Maximum outlet pressure 60,000 psi (4,137 bar)
