Section 2
Installation
20479262
9-2010/Rev 02
2-10
3. Loosen the gland nut and insert the tubing through the collet. The end of the tubing
should just make contact with the cutting blade. Loosely tighten the gland nut to slightly
grip the tubing.
4. Turn the feed nut counter-clockwise 1/4 turn to retract the cutting blade away from the
tubing, and tighten the gland nut with a wrench.
5. Apply a liberal amount of cutting oil to the exposed end of the tubing, the cutting blade
and through the lubrication channel at the cutter handle.
6. Apply cutting oil frequently and liberally throughout the cutting operation. A medium
weight cutting oil with high sulfur content is recommended.
7. Turn the feed nut clockwise until the cutting blade contacts the end of the tubing.
8. In a smooth, continuous motion, turn the cutter handle in a clockwise direction.
Simultaneously turn the feed nut in a clockwise direction to establish a constant feed. Do
not remove too much material at once; the cutting blade should make light, uninterrupted
cuts.
NOTE
Before interrupting the cut, back the cutter blade away from the tubing. Use
compressed air or a small brush to remove the accumulation of chips from the
blade and the tubing throughout the coning operation.
9. Continue the operation until the feed nut bottoms on the housing. Turn the cutter handle
several more rotations to face-off the end of the cone.
10. Retract the cutter blade, loosen the gland nut and remove the tubing. Inspect the cone for
surface finish and completeness.
NOTE
Clean the machining chips from the blade and from the collet before coning the
next tube.
Power Coning
1. Secure the tubing in a tube vise. No more than the recommended length of tubing should
extend beyond the face of the vice. See Table 2-9, Recommended Extension Length.
2. Mount the coning tool in a 3/8-inch or 1/2-inch, variable speed power drill. Apply cutting
oil to the end of the tube and slide the coning tool on the tubing.
3. Apply steady pressure against the end of the tubing while the cone is being cut.
4. Apply cutting oil frequently and liberally throughout the cutting operation. A medium
weight cutting oil with high sulfur content is recommended.
5. The tool will stop cutting when the tube angle and facing is complete.
