Section 8
High Pressure Water System
20479291
2-2012/Rev 04
8-7
Specialized Maintenance Tools
KMT Waterjet has designed tools to facilitate the removal and installation of specialized system
components. These tools are illustrated in Figure 8-6, Specialized Maintenance Tools, and part
numbers are provided in Table 8-2.
Figure 8-6: Specialized Maintenance Tools
Table 8-2
Specialized Maintenance Tools
High Pressure Water System
Part Number
Plunger Removal Tool 20477460
Plug 10079523 (3/8”)
Gland Fitting 10078129 (3/8”)
Seal Removal Tool 10148674
End Cap Wrench 80079239 (6x 8x)
Cylinder Wrench 05066139
Seal Removal Tool Stand 80078330
Vee Block Cradle 20484961
